Steam Heating Fermentation Tank
Beer Fermenter
Fermenting Equipment Bewing beer 10HL;
-Highest quality;
-Competitive price
-Best service
-1~3 years warranty for all our products Item: Beer equipment fermentation tank
Application: Beer fermenter is widely used in such industries as brewing, dairy product processing, etc
Feature and advantage:
1, Capacity: 40015000L
2, Material: SUS 304 or 316L
3, Finishing: Mirror polishing(Roughness: Ra≤ 0.4um)
4, Cylindercone bottom shape and dished top head
5, Insulation: PU foam jacket on the side and bottom(4080mm)
6, High quality material. The quality of stainless steel from different suppliers can be very different, All our materials are from famous suppliers(suppliers name available)
OEM order supported
Special disign or requirement from customers supported
Products Characteristics:
Fermentation tank is a kind of equipment, which can mechanical agitation and fermentation of materials. This device uses the inner loop method, with the mixing propeller to scatter and broken bubble, which dissolved oxygen rate is high and the mixing effect is good. Tank uses imported SUS304 or 316L stainless steel. Inside of the tank is equipped with automatic spray cleaning machine. We ensure production processes comply with GMP requirements.
Product applications:
Widely used in dairy products, beverages, biological engineering, pharmaceutical, fine chemical, etc. Stainless steel fermentation tank installs with interlining, insulation, which can heating, cooling, heat preservation.
Wenzhou wanyuan food machinery factory- - Fermentation tank
The below is the fermentation tank specification:
| CAPACITY | SPEED(R/MIN) | WORKING PRESSURE | TEST PRESSURE | MOTO POWER(KW) | TEMPERATURE |
| (MPa) |
| 100L | 110-220 | 0.15 | 0.30 | 0.37 | ≤1200C |
| 200L | 110-220 | 0.15 | 0.30 | 0.5 | ≤1200C |
| 300L | 110-220 | 0.15 | 0.30 | 0.5 | ≤1200C |
| 500L | 110-220 | 0.15 | 0.30 | 0.75 | ≤1200C |
| 600L | 110-220 | 0.15 | 0.30 | 0.75 | ≤1200C |
| 800L | 110-220 | 0.15 | 0.30 | 1.1 | ≤1200C |
| 1000L | 110-220 | 0.15 | 0.30 | 1.1 | ≤1200C |
| 2000L | 110-220 | 0.15 | 0.30 | 2.2 | ≤1200C |
| 3000L | 110-220 | 0.15 | 0.30 | 3.0 | ≤1200C |
| 5000L | 110-220 | 0.15 | 0.30 | 3.0 | ≤1200C |
| 8000L | 110-220 | 0.15 | 0.30 | 4.0 | ≤1200C |
| 10m 3 | 110-220 | 0.15 | 0.30 | 5.5 | ≤1200C |
| 20m 3 | 110-220 | 0.15 | 0.30 | 5.5 | ≤1200C |
| 40m 3 | 110-220 | 0.15 | 0.30 | 7.5 | ≤1200C |
| 60m 3 | 110-220 | 0.15 | 0.30 | 7.5 | ≤1200C |
| 100m 3 | 110-220 | 0.15 | 0.30 | 10.0 | ≤1200C |
