Stainless Steel Emulsification Tank High Speed Mixing Sugar Pot

Customization:Available
Additional Capabilities:Milling
Application:Liquid with Suspended Solids, Viscous Fluid, Liquid
Quantity:

Basic Info.

Model NO.
WY1500
Certification
CE, ISO
Condition
New
Main Material
Stainless Steel
Mixing Drum Shape
Conical
Stirring Type
Spiral
Working
High Speed Mixer
Capacity
1500L, Can Be Customized
Material
Stainless Steel 304
Mixing Speed
2800rpm
Structure
Conical, Square with Manhole
Mixer Type
Agitator
Layout Type
Verticle
Operating type
Cycle Operating
Transport Package
Wooden Case
Specification
SUS304
Trademark
Wanyuan
Origin
Wenzhou China
Production Capacity
5000

Product Description

Stainless steel Emulsification tank High speed mixing sugar pot
1. Made of stainless steel
2. Mixing milk, juice, or any other viscous liquid, Like sugar, egg whites the need of high speed stirring
3. Customized mixing tank capacity

High speed blending tank is made of quality stainless steel with 360 cleaning nozzle, polyester insulation, unseal or seal top. The cutting head is fabricated with advanced technique with creates extreme strong on flow while working. Especially for fruit juice and beverage producing, it can be the best tool for stabilities solution and realize cold blending which enhances efficiency and energy saving greatly.

Mixing Tank <mixing tanks> mainly made of stainless steel, used for mixing different liquid together.
Also, you can use this mixing tanks to mix liquid and power to make a mixture.
Mixing tanks can be with different mixing speed. Such as 36rpm, 60rpm fixed mixing speed. But due to some production request, you may need the mixing tanks with variable speed, such as 8 to 140rpm, 40 to 200rpm mixing speed, or 200 to 1000 rpm mixing speed. In special reqeust, we can use VFD<Variable Frequency Drive> to meet your special mixing speed request.

Wenzhou wanyuan food machinery factory mainly produce stainless steel mixing tanks for milk, juice, beverage, cosmetic, detergent as well as chemical product.

Wenzhou wanyuan food machinery factory- Mixing tank / Stirred tank

Our Mixing tank capacity can be 300L, 500L, 1000L, 1500L or any other capacity you need.
Specification  Motor speed Power Dimension Inlet diameter Out let diameter
300L 1750r/min 7.5KW 1130×770 Φ40 Φ50
500L 1750r/min 7.5KW 1380×1020 Φ40 Φ50
1000L 1750r/min 7.5KW 1510×1150 Φ40 Φ50
1500L 1750r/min 7.5KW 1610×1250 Φ40 Φ50
2000L 1750r/min 7.5KW 1810×1450 Φ40 Φ50
