1, Usage:
Alcohol refine tower can use for distillate low concentration of the distillation to remove some impurities and moisture, and get the concentration of 95% alcohol, in order to effectively improve the utilization of alcohol. Dilute alcohol in the pharmaceutical, food, chemical and other to recyclend reduce production costs. alcohol by maximum lization of industries
II .Technical characteristics:
•Alcohol distillation in the closed equipment ,meet safety production and environmental requirements.
•The stainless steel ripple packing material, make contact area increase, more conducive for the vapor-liquid mass transfer.
•lnfinite reflux and whole transfer operation don't require adjustment of the reflux ratio by manual, more quickly and more convenient. •Steam Heating and automatic temperature control, make operation more easily.
•Heating methods have outside circle and U-shaped tube two types for your choose.
•Less than 1% of alcohol concentration in the waste.
3, Structure:
This equipment composed by the reboiler, the tower body, condenser, cooler, liquid receiving tank and sanitary valves, pipe.
4, Spec and main technical standards
Model
Parameters | JH200 | JH300 | JH400 | JH500 | JH600 | JH800 |
| Tower Diameter:MM | 200 | 300 | 400 | 500 | 600 | 800 |
| Tower Height:MM | 7200 | 7200 | 7200 | 7200 | 7200 | 9000 |
| BoilingTank Capacity:L | 600 | 1000 | 1500 | 2000 | 3000 | 4000 |
| Recycle Capacity:Kg/h | 60~80 | 90~100 | 120~150 | 200~300 | 350~400 | 550~600 |
| Alcohol concentration:% | 93~95 | 93~95 | 93~95 | 93~95 | 93~95 | 93~95 |
| Total Weight:Kg | 1050 | 1400 | 1900 | 2400 | 3300 | 4200 |
| Dimension:m | 2.5*0.8*10 | 2.6*0.9*10 | 2.8*10*11 | 3.0*10*11 | 3.5*1.4*12 | 4.2*17*14 |
