Stainless steel Spherical Type Concentrator
This concentrator is suitable for concentrating the fluid materials of traditional medicine, western medicine, grape suger, strach, gourmet powder, food and milk products, chemical industry, especially for thermal sensitive matter low temperature vacuum concentration. Our factory has carried out careful accu mulation and meticulous design and reform and got more profits than the orginal characteristic. You can select the series concentrator in techical parameters according to your concentration degree.
Wenzhou wanyuan food machinery factory
The following is concentrating tank parameter
| model | QN-200 | QN-500 | QN-700 | QN-1000 | QN-1500 | QN-2000 |
| evaporating capacity(kg/h) | 60 | 110 | 150 | 200 | 300 | 400 |
| volume(L) | 200 | 500 | 700 | 1000 | 1500 | 2000 |
| steam pressure(MPa) | <0.1 |
| vacuum degree(Mpa) | -0.08 |
| heating area(m2) | 0.9 | 1.5 | 2.1 | 2.7 | 3.5 | 4.0 |
| cooling area(m2) | 1.7 | 3.4 | 5.0 | 7.0 | 8.5 | 10 |
| dimension(m) | 1.7*0.9*2.3 | 2.3*1.1*2.6 | 2.3*1.3*2.6 | 2.7*1.5*2.9 | 3*1.6*3 | 3.1*1.8*3 |
