Sanitary Stainless Steel Square Type Emulsifying Tank for Juice

Customization:Available
Additional Capabilities:Milling
Application:Liquid with Suspended Solids, Viscous Fluid, Liquid
Quantity:

Basic Info.

Model NO.
WY1000
Certification
CE, ISO
Condition
New
Main Material
Stainless Steel
Mixing Drum Shape
Conical
Stirring Type
Spiral
Working
High Speed Mixer
Capacity
1500L, Can Be Customized
Material
Stainless Steel 304
Mixing Speed
2800rpm
Structure
Conical, Square with Manhole
Mixer Type
Agitator
Layout Type
Verticle
Operating type
Cycle Operating
Transport Package
Wooden Case
Specification
SUS304
Trademark
Wanyuan
Origin
Wenzhou China
HS Code
8438800000
Production Capacity
5000

Product Description

Sanitary Stainless Steel Square Type Emulsifying Tank for Milk

The high speed emulsification tank adopts high speed impeller bottom mixing device, to the sugar, milk powder, glue and other additives has a good dissolve emulsification, is the highest efficiency products in the similar products.

Usage
1. The food and beverage: Dairy products, ice cream, chocolate, soy milk, fruit juice and jam.
2. Chemical industry: Lubricating oil, grease, heavy oil emulsification, diesel oil emulsion, disinfectant, pesticides, photographic latex, rubber slurry, resin pulp, thickener, essence, silicone material, carbon black, magnesium oxide, titanium dioxide, prevent adhesive, defoaming agent, sealant, etc.
3. Cosmetics industry: Detergent, conditioners, shampoo, lotion, perfume.
4. The pharmaceutical industry: Injections, medicine emulsion, medicine cream, health care products, medicine slurry preparation;
5. Paper industry: Pulp, adhesive, note agent, resin emulsion.

Characteristics
Centrifugal high speed emulsifier can produce huge rotating suction, absorbing materials in the top, then throw to the stator with high speed, after shearing, collision and smashing between the stator and shear, materials collected to export and experiment. At the same time, the anti-swirl flap in tank bottom force into troubled force, so that the materials can mix even, prevent powder in liquid surface accumulation, and to achieve the purpose of emulsified hydration.

Wenzhou Longwan wanyuan food machinery factory mainly produce stainless steel Melting Tanks for milk, juice, beverage, cosmetic, detergent as well as chemical product.

Mixing tank / Stirred tank / Melting Tank / Emulsifying Tank

Our Melting Tank capacity can be 300L, 500L, 1000L, 1500L or any other capacity you need.

Specification  Motor speed Power Dimension Inlet diameter Out let diameter
300L 1750r/min 7.5KW 1130×770 Φ40 Φ50
500L 1750r/min 7.5KW 1380×1020 Φ40 Φ50
1000L 1750r/min 7.5KW 1510×1150 Φ40 Φ50
1500L 1750r/min 7.5KW 1610×1250 Φ40 Φ50
2000L 1750r/min 7.5KW 1810×1450 Φ40 Φ50
