Single-deck mixing tank with manhole
1. Made of stainless steel 304/316
2. Used to mixing liquid product
3. Mixing speed can be customized: 50L-10T
Mixing tanks is an ideal one for mixing and emulsifying process applied by the trades of medicine, chemical and foodstuff.
Stainless steel mixing and melting tank series
Stainless steel storage tank series
Homgenizer and vacuum mixing tank
Homogenizing and emulsifying machinery
Herbal Extraction and concentration/evaporation machinery
TIPS:
We are manufacture of stainless steel mixing tank steam heating or electric heating.
If you are in need of any tanks, please let me know your detail request, so that we can customized the tank for you.
Wenzhou wanyuan food machinery factory- - Mixing tank
Single-deck mixing tank with manhole
The below is Mixing tank specifications:
| volume (L) | Dimension
(D× h ) (mm) | Total height (mm) | Diameter Of inlet
& outlet | Heat preservation layer (mm) |
| 500 | 840 × 1000 | 2250 | 38 | 60 |
| 600 | 920 × 1000 | 2300 | 38 | 60
|
| 700 | 990 × 1000 | 2300 | 38 | 60 |
| 800 | 950 × 1220 | 2500 | 38 | 60 |
| 900 | 1010 × 1220 | 2500 | 38 | 60 |
| 1000 | 1060 × 1220 | 2550 | 51 | 60 |
| 1500 | 1160 × 1500 | 2850 | 51 | 60 |
| 2000 | 1340 × 1500 | 2900 | 51 | 60 |
| 3000 | 1410 × 2000 | 3400 | 51 | 60 |
| 4000 | 1620 × 2000 | 3450 | 51 | 60 |
| 5000 | 1810 × 2000 | 3500 | 51 | 60 |
