Fermentation tank is widely used in dairy products, beverages, biological engineering, pharmaceutical, fine chemical industries, tanks with interlining, insulation, heating, cooling, heat preservation. Tanks and filling head up and down (or cone) adopt spinning R Angle processing, fermentation tank wall by the mirror polishing processing, no health dead Angle, and totally enclosed design to ensure that the material has always been a pollution-free mixing, fermentation, under the condition of equipment is equipped with air breathing hole, CIP cleaning nozzle and manhole device, etc
Fermenter Application:
1. Used as storage and fermentation tank in wine, dairy, etc industries;
2. Applicable in the filed of food, dairy, juice, chemical and biological fields.
Fermenter Structure:
1. Volume from 300L-15000L, could be customized according to customer needs.
2. Material used sanitary stainless steel.
3. Three layer strcture: Inner body, jacket and insulated, insulated layer filled with insulation material.
4. Conical bottom shape, cooling jacketed could adopt dimple jacketed, arched and corrugated access jacket.
The following is parameter of Fermentation tank:
| Parameters | 500L | 1000L | 1500L | 2000L | 3000L | 5000L | 10000L |
Inner dimension
( Diameter×high)mm | 700× 1200 | 900× 1500 | 1100× 1600 | 1200× 1800 | 1200× 2600 | 1400× 3000 | 1800× 3600 |
| Mixing speed (r/min) | 400 | 300 | 260 | 240 | 220 | 200 | 150 |
| Motor power (Kw) | 2.2 | 3.0 | 4.0 | 4.0 | 5.5 | 11 | 22 |
