May collapse dyadic interlayer boiler
1. Oil jacketed cooking kettle
2. Double layer kettle structure
3. Tri-leg mounted cooking pot / tilting cooking kettle
Gas heating jacketed Kettle, Tri-leg mounted, self-contained, stationary, oil Jacketed. Type 304 Stainless Steel Kettle and Supports
Nature gas jacket kettle is widely used for the cooking of fruit, vegetable, soup, candy. Also used in the processing of sweets, pharmacy, dairy, alcohol, pastry, beverage, succade and so on.
Wenzhou longwan wanyuan food machinery factory
Nature gas heating jacketed kettle can also be used for large-scale restaurants and dining rooms, which can improve processing quality and working condition, and shorten the processing time.
This cooking kettle takes 110V to 480V voltage <can be customized> as its heat source, with electrical bar, electric couple and conduction oil in interlayer, as high as 250° C, controlled by electric cabinet. Our jacketed kettle has advantages of big heating area, high heat-efficiency, homogeneous heating, short boiling time, controllable heating temperature ect.
Jacketed Kettle, Electric Jacketed Kettle, Oil Jacketed Kettle, Nature gas heating jacketed kettle, cooking vat
The inner layer of this nature gas heating jacketed kettle is made of austenitic stainless steel, equipped with pressure gauge, safety valve and electric cabinet, featured by good appearance, easy operation and reliable insulating property.
Wenzhou wanyuan food machinery factory- - Jacketed kettle/ Sandwich Boiler
Jacketed Kettle, Electric Jacketed Kettle, Oil Jacketed Kettle specification
The below is Jacketed kettle specification:
| Model | DG-200 | DG-100 |
| Jacketed pot | diameter(mm) | Φ800 | Φ700 |
| depth(mm) | 550 | 500 |
| Total capacity (L) | 200 | 100 |
| Material in/out pipe | 1/2" | 3/4" |
| Heating power(kw) | 12 | 18 |
| Boiling time (min) | ~13 | ~10 |
| Heating area(m2) | 1.13 | 0.58 |
| Design temperature (degree C) | 180 | 180 |
| Max working temp (degree C) | 151 | 151 |
| Design pressure (MPa) | 0.095 | 0.095 |
| Max working pressure(MPa) | 0.095 | 0.095 |
| Max tilting Angle | 90° | 90° |
| overall dimension | Length (mm) | 1100 | 1000 |
| Width (mm) | 850 | 750 |
| Height (mm) | 1450 | 1100 |
| FOB Price | | 1
|
