1500L Large Capacity Steam Heating Jacketed Cooking Pot

Customization:	Available
Type:	Cooking and Mixing
Voltage:	According to Your Local Voltage

Quantity:



Inquire Add to Basket

Product Description

Basic Info.

Model NO.

GTJ-500

Customized

Cooking Kettle Capacity

1500L

Material

SUS304

Number of Layer

Two-Layer/ Three-Layer

Agitator

Anchor Agitator/ Agitator with Scraper

Structure

Vertical

Heating Mode

Steam Heating

Mixing Power

7.5kw

Transport Package

Wooden Case

Specification

CE

Origin

Wenzhou China

Product Description

1500L large capacity Steam heating jacketed cooking pot
Cooking for tomato sauces, Ketchup, tomato soup, fruit jams (mango, guava, etc.), coconut syrup, etc

Our factory dedicated to producing cooking pot <also named jacketed kettle> according to the customer request.
1. Kettle capacity 50L, 100L, 200L even 1500L<customized>,
2. Tiltable or vertical type as you need,
3. Anchor agitator/ Agitator with Scraper
4. Fixed mixing speed or Gearbox 20-60rpm, 50-120rpm, 120-300rpm etc..

As long as your request is reasonable, we can all meet!
What are your waiting for!!! Contact me directly!!!

The following is 1500L vertical steam heating jacketed cooking pot

1500L Large Capacity Steam Heating Jacketed Cooking Pot

Jacketed kettle or electric jacketed kettle can be designed into different type: Tilting type cooking kettle and vertical type cooking kettle. Tilting jacketed cooking kettle is designed with a tiltable device, you can turn the kettle or pot over for discharge after cooking. Gas Heating tilting jacketed kettle with scraper stirrer.

Both of tilting cooking pot and verticle cooking pot can be designed with mixer or without mixer.

Our jacket kettle normally used for producing sauces, pasta, vegetables, soups, juice, meat, candy and other food products. It also can be used as simple sterilization boiler.

Wenzhou longwan wanyuan food machinery factory— — Jacketed cooking pot
Cooking kettle / cooking pan / cooking vat / cooking pot
Here below is the specification of our jacketed kettke:

Specification for gas heating jacketed kettle

Model	GTJ-100	GTJ-200	GTJ-300	GTJ-500	GTJ-600
Volume (L)	100	200	300	500	600
Pot Size (mm)	Φ700×530	Φ800×580	Φ900×630	Φ1100×730	Φ1200×780
Working Pressure(MPa)	≤0.3(jacket)
Working Temperature	≤100 degree C (material in pot) ≤143 degree C(jacket)
Blending Speed (r/min)	35
Steam Inlet(DN)	20	20	20	25	25
Heating Area(m2)	0.7	0.95	1.2	1.8	2.2
Evaporative Power(kg/h)	45	80	100	140	160
Steam Consumption (kg/h)	50	90	112	160	182
Motor Power (KW)	0.37	0.55	0.55	1.1	1.1
Dimension(cm)	115×80×100	135×90×107	145×100×115	165×120×136	176×130×146
Weight(kg)	180	200	220	290	320
