Stirred-free tilting steam heating jacketed kettle 1. Cooking milk, juice, tomato puree, paste
2. Kettle capacity 50L, 100L, 200L <customized>
3. Tiltable without mixing scraper or mixing paddle .
Our jacket kettle normally used for producing sauces, pasta, vegetables, soups, juice, meat, candy and other food products. It also can be used as simple sterilization boiler.
Wenzhou wanyuan food machinery factory——Jacketed kettle
Cooking kettle / cooking pan / cooking vat / specification
Here below is our Jacketed kettle specification:
| working pressure(a) | 0.30.5 |
| evaporation pressure(kgh) | 30 | 40 | 50 | 65 | 75 | 100 | 150 |
| heating area() | 0.4 | 0.45 | 0.76 | 1 | 1.15 | 1.44 | 1.9 |
| Energy consumption (kgh) | 33 | 44 | 55 | 72 | 90 | 110 | 165 |
| equipment form | tilting-type ,vertical; |
| Heating Method | steam heating |
| equipment weight | 170 | 190 | 210 | 230 | 320 | 360 | 485 |
| outline dimension | 700×600 800×650 1350×660 1400×700 1450×800 1500×850 1600×900 |
| L×W×H() | ×830 ×950 ×1000 ×1100 ×1110 ×1140 1150× |
