600L Automatic Tilting Rotary Steam Jacketed Cooking Pot

Customization:	Available
Power Source:	Steam
Timing Device:	With Timing Device

Quantity:



Inquire Add to Basket

Product Description

Basic Info.

Model NO.

GTJ-600

Voltage

110V/220V/380V/415V

Customized

Pot Capacity

50liter to 600L Customized

Pot Type

Jacketed / Double Layer

Way of Discharge

Tiltable or Discharge From Bottom

Heating Type

Steam Heating / Hot Water Heating

Mixing Device

Anchor Type

Scraper

with Scraper or Not <Customized>

Construction Material

Stainless Steel 304 / 316

Transport Package

Wooden Case

Origin

Wenzhou China

Product Description

600L Automatic tilting rotary steam pot steam heating jacketed cooking kettle
1. Cooking kettle capacity 50~600Liter
2. Use steam as heating resource
3. Tiltable, easy to discharge

Jacketed kettle introduction
Jacketed kettle can be designed into different heating type, such as
1. Steam heating jacketed kettle
2. Electric heating jacketed cooking kettle
3. Gas heating jacketed kettle

Please through the following pictures to learn more about our new steam heating jacketed cooking kettle.

Kettle features:
1. Compared with the previous Jacketed cooking kettle, add a tilting motor, can tilt by switch control;
2. Add a steam rotary joint.
600L Automatic Tilting Rotary Steam Jacketed Cooking Pot

Steam heating jacketed kettle capacity:
As a manufacture of steam jacketed kettle<cooking pot or jacketed cooking vat>, wenzhou longwan wanyuan food machinery offer different cooking kettle capacity according to your request.
You can choose 50L cooking kettle, 100L cooking kettle, or 200L cooking pot. You can also choose any other customized capacity cooking kettle.
If you need big capacity steam cooking kettle, such as 1500L double layer cooking kettle, we can also offer.

This is tilting type steam heating jacketed kettle:
Steam jacket kettle can be designed into vertical jacketed kettle and tilting jacketed kettle
Vertical jacket kettle in stainless steel 304, which with jacket inside the walls for steam inject and heating. It takes the steam as thermal source. The inner surface contacted with product are all SUS304 or SUS316, which is mirror finished. Outer surface is matt finished.

Tilting jacketed kettle use the same jacketed, the difference between tilting jacketed kettle and vertical jacketed kettle is only the way of discharge, vertical cooking pan or cooking vat have a drainage pipe at the pot bottom while tilting cooking kettle do not have such discharge pipe. When you finished one batch of cooking by tilting jacketed kettle, you only need to turn the pot over the liquid in the jacketed pot will flow out by its gravity.

wenzhou wanyuan food machinery factory—Jacketed kettle
600L Automatic tilting rotary steam pot steam heating jacketed cooking kettle

Here below is the specification of our steam heating jacketed kettle

Model	GTJ-100	GTJ-200	GTJ-300	GTJ-500	GTJ-600
Volume (L)	100	200	300	500	600
Pot Size (mm)	Φ700×530	Φ800×580	Φ900×630	Φ1100×730	Φ1200×780
Working Pressure(MPa)	≤0.3(jacket)
Working Temperature	≤100 degree C (material in pot) ≤143 degree C(jacket)
Blending Speed (r/min)	35
Steam Inlet(DN)	20	20	20	25	25
Heating Area(m2)	0.7	0.95	1.2	1.8	2.2
Evaporative Power(kg/h)	45	80	100	140	160
Steam Consumption (kg/h)	50	90	112	160	182
Motor Power (KW)	0.37	0.55	0.55	1.1	1.1
Dimension(cm)	115×80×100	135×90×107	145×100×115	165×120×136	176×130×146
Weight(kg)	180	200	220	290	320
