High Quality Sanitary Stainless Steel Fermentation Tank
Fermentation Tank
Fermentation tank is used for mechanical mixing and fermentation of matters. This equipment adopts internal circulation to disperse and smash air bubbles by mixing oar, fast dissolving oxygen, good in mixing effect. The tank body adopts SUS304 stainless steel. Inside the tank is equipped with automatic sprinkle-nozzle, to ensure production process conforms to GMP standard.
Wenzhou wanyuan food machinery factory mainly produce stainless steel mixing tanks for milk, juice, beverage, cosmetic, detergent as well as chemical product.
Wenzhou wanyuan food machinery factory- Fermentation Tank/ fermentation cylinder
Our Fermentation Tank capacity can be 50L, 200L, 500L, 2000L or any other capacity you need.
| volume (L) | Dimension
(D× h ) (mm) | Total height (mm) | Diameter Of inlet
& outlet | Heat preservation layer (mm) |
| 500 | 840 × 1000 | 2250 | 38 | 60 |
| 600 | 920 × 1000 | 2300 | 38 | 60 |
| 700 | 990 × 1000 | 2300 | 38 | 60 |
| 800 | 950 × 1220 | 2500 | 38 | 60 |
| 900 | 1010 × 1220 | 2500 | 38 | 60 |
| 1000 | 1060 × 1220 | 2550 | 51 | 60 |
| 1500 | 1160 × 1500 | 2850 | 51 | 60 |
| 2000 | 1340 × 1500 | 2900 | 51 | 60 |
| 3000 | 1410 × 2000 | 3400 | 51 | 60 |
| 4000 | 1620 × 2000 | 3450 | 51 | 60 |
| 5000 | 1810 × 2000 | 3500 | 51 | 60 |
