Aging tank <cooling and heating tank>is a king of process tank which is made of stainless steel. Aging tank <cooling and heating tank>can be designed with different capacity, such as 500L aging tank <cooling and heating tank>, 1000L againg tank <cooling and heating tank> or any other capacity, big or small.
Aging Tank <cooling and heating tank>Usage
Most aging tanks <cooling and heating tank> are used in food processing industrial. We can see aging tanks in a milk production factory, also, we can see aging tanks <cooling and heating tank> in juice productiong workshop.
Aging tank structure <cooling and heating tank>
Aging tank <cooling and heating tank> is designed with 3 layer, or we can call it as a tri-layer mixing tank or 3 layer aging tank <cooling and heating tank>.
Inner layre of our aging tank <cooling and heating tank> is made of stainless steel. Usually AISI304
The middle layer of the aging tank <cooling and heating tank>is a jacket, it can be dimple jacket or spiral tube or coil. You can access hot water or steam to the jacket for heating. Also you can access cooling water to the jacket for cooling. That is why we call aging tank as cooling and heating tanks.
Outside the aging tank <cooling and heating tank> body, there is a layer of heat preservation.
Aging tank <cooling and heating tank> picture
Aging tank <cooling and heating tank> specification
| Capacity | 500 L | 1000L | 2000 L |
| Working Pressure | 0.09 MPa | 0.09 MPa | 0.09 MPa |
| Test Pressure | 0.15 MPa | 0.15 MPa | 0.15 MPa |
| Stirring Speed | 36 r/min | 36 r/min | 36 r/min |
| Heating Area | 2 m² | 4.5 | 7.5 m² |
| Material in/outlet | DN40 | 40 | DN40 |
| Heating Power | 14 KW | 12 | 14 KW |
| Overall Dimension | Φ1350×1900 | Φ1600×2200 | Φ1900×2500 |
| Weight | 720KG | >980 | 1100 |
