Stainless Steel Cip Cleaning Machine System

Customization:	Available
Clean Type:	Clean-in-Place (Cip)
Cleaning Process:	Hot Water Cleaning

Quantity:



Inquire Add to Basket

Product Description

Basic Info.

Model NO.

WANYUAN

Processing Procedure

Alkali Cleaning,Acid Cleaning,Hot Water Cleaning

Capacity

1-15t/H

Process

Frozen and Chilled

Transport Package

Wooden Case

Origin

Wenzhou China

Product Description

Stainless Steel Cip Cleaning Machine System

CIP cleaning system can not only clean machine, but also control the cleaning of microorganism method.

The CIP cleaning system has the following advantage:
1, make the production plan rationalize and the exaltation produce an ability.
2, can not only reach a good cleaning performance, but also can raise the quality of product.
3, can prevent cleaning homework from dangerous, economical labor force.
4, can save the steam, water and production cost.
5, can increase the usage time of the machine you want to clean and maintain.
6, This CIP cleaning system is detachable and movable,

CIP system is total-automatic self-case unit, containing a water tank, an acid tank, a lye tank, some necessary pumps, valves and a set of monitor devices, such as temperature sensor, density sensor and liquid level sensor and so on. Technical not only supply customers a standard CIP unit, but aso manufacture a special CIP system following your special requirement.

CIP unit contains self-automatic control program, including completed cleaning process. The program includes all-process cleaning program, acid cleaning program and lye cleaning program. Both of the cleaning water and the dissolvent is acceptable for CIP system. The temperature and the desity of the cleaning water can be enacted and controlled accurately. What is more, the density of the cleaning solution can be mixed automatically.

Stainless Steel Cip Cleaning Machine System

Total-automatic control to provide safety operating interface.
Total-automatic add acid/alkali depending on the density monitor, which self control the density of the dissolvent. So that it can reduce the demand of human resource, and make sure the safety of the human.

Adopt the tubular heat exchanger, bear high pressure resistance, no block, and few maintaince fee.
Optimized CIP cleaning function can reduce the times of CIP cleaning.

Stainless Steel Cip Cleaning Machine System

Processing:	Washer,online Cleaning the beverage line	Condition:	New	Place of Origin:	ZhejiangChina (Mainland)
Brand Name:	Wanyuan	Model Number:	CIP-300	Voltage:	380
Weight:	1000kg	Dimension(LWH):	220010001600mm	Processing Types:	Juice, carbonated beverage machine
Certification:	CE	Warranty:	1 year	After-sales Service Provided:	Engineers available to service machinery overseas
Machine name:	electric cip cleaning system	Material:	SUS304,SUS316	Feature:	Automatic, high quality
Control:	Button
