Electric Cip Cleaning System

Customization:	Available
Clean Type:	Clean-in-Place (Cip)
Cleaning Process:	Hot Water Cleaning

Quantity:



Inquire Add to Basket

Product Description

Basic Info.

Model NO.

WY-1000

Processing Procedure

Alkali Cleaning,Acid Cleaning,Hot Water Cleaning

Capacity

1-15t/H

Process

Frozen and Chilled

Transport Package

Wooden Case

Specification

SUS304

Trademark

Wanyuan

Origin

Wenzhou China

Production Capacity

5000

Product Description

Electric CIP Cleaning System/Sanitary Stainless steel CIP Cleaning System/CIP cleaning system pipe cleaning system

CIP cleaning device provides manual, semi-automatic and automatic modes for customer selection.

CIP (cleaning in-placeis a designed for automatic cleaning by recirculation detergent and rinse solutions without major disassembly and assembly work.

1. The CIPsystem can be designed to clean one part of the plant while other areas continue to produce product. The CIP systems provide reserviories for detergent and rinse solutions as well as pumping and heating capabilities for the solution. Computer control handles the programs sequences of washing and rinsing material is recycled through the vessel, pump, valves and other process equipment in the flow system.

2. The cleaning can be carried out with automated or mannal systems is a reliable process that meets the stringent hygiene regulations demanded by the food, dairy, beberage, biotechnology and pharmaceutical industries.

3. Cip system has such advanges as energy-saving, high efficiency, operator safety and easy to operate and manintain.

Capacity	In Water tank	0.45 M 3
Capacity	In Acid-base tanks	1000L
Operating pressure	In Water tank	Normal
	In Acid-base tanks	Normal
	Steam pipe	0.3-0.6Mpa
Operating temperature	In Water tank	Normal
	In Acid-base tanks	60-80 0 C
	Steam pipe	<138.8 0 C
Cleaning order	Water → alkali liquor → water → acid liquor → water
	Inlet / outlet	DN40 Tr55×3
	Flow rate	10T/H
	Head of delivery	28m
centrifugal pump	Motor power	2.2KW
	Motor Speed	2880r/min
	500KG
	L2200×W1200×H1550mm
Material	SS304
