AISI 304 Sanitary Milk Pump

Customization:	Available
Power Source:	Electric
Automatic Grade:	Semi-Automatic

Quantity:



Inquire Add to Basket

Product Description

Basic Info.

Model NO.

CP-5-24

Customized

Model Number

Ss304

Usage

Dairy &Food&Water

Fuel

Sanitary Centrifugal Pump

Pressure

High Pressure

Theory

Centrifugal Pump

Transport Package

Wooden Case

Origin

Wenzhou China

Product Description

Milk pump / Sanitary Beverage Pump 3L/H Flow Rate Pump
Specifications
1. Single stage, back pullout, SS covered
2. Food grade stainless steel, GMP standard
3. Competitive price, long serivce life
Overview
SP stainless steel milk pump is a special design has impeller and shaft sleeve are forged integrally, and directly installed on the output shaft of the motor.
Advantage: High concentricity of shaft, strong rigidity, small vibration and prolonged service life of mechanical seal.
Disadvantage: Only suitable for small power, the maximum power rate is 2.2kw.

Milk pump / Sanitary Beverage Pump 3L/H Flow Rate Pump
Applications
SP centrifugal pump is a sanitary centrifugal pump that meets the highest sanitary requirements for use in the food-processing and pharmaceutical, dairy, milk, bear industries.
Some of its uses include processes in the brewing, dairies and beverage industries in general, and with the appropriate options it can also be used in complex applications such as evaporators, concentrators, distillation towers, decanting of syrups, and purified-water loops in the pharmaceutical industry.

Working principle
Housed inside the casing, the impeller rotates in conjunction with the pump shaft. With this arrangement, the impeller blades convey energy to the fluid in the form of kinetic energy and pressure energy.
This pump is not reversible by simple reversal of the direction of rotation. The direction of rotation is clockwise when the pump is viewed from the rear side of the motor.

Technical parameters
Design and features
Different connections standard: DIN, SMS, JIS, ISO.
Open impeller manufactured with stainless steel investment casting technology.
Sanitary mechanical seal.
Pump certified according to 3A sanitary standards.
Very robust stainless steel cast lantern.
Pump support from AISI 304.
AISI 304 Sanitary Milk Pump

Wenzhou wanyuan food machinery factory
Milk pump / Sanitary Beverage Pump 3L/H Flow Rate Pump
Here below the sanitary beverage pump specification

Parts in contact with pumped media	AISI 316L or 304
Other parts in stainless steel	AISI 304
Gaskets (standard)	EPDM (FDA)
Mechanical seal (standard)	graphite/Sic/EPDM
Inside surface finishing	Ra < 0.4 um.
Outside surface finishing	Mirror polished
