Ss304 Rotary Lobe Pump for Chocolate, Honey, Ice Cream, Cosmetic
Advantage:
1. Stable work
2. Low noise
3. Easy assembly and disassembly
4. Conveniently clean
Summarize:
ZB3A Stainless Steel Rotor Pump can be also called colloidal pump. All liquid flowing parts are made of stainless steel. It can be transmit high viscosity, thickness and with particle medium. The temperature can be -30 to 200 degree. There is no touch between the two rotors. No abrasion ever after long time operation.
Usage:
1. Dairy product: Sour and fresh milk, ice cream, cream slices and whey
Beverage: Beer, mash, yeast, aerated water, concentrated fruit solution and fruit juice drinks
2. Food: Ketchup, fruit paste, vegetable pulp, pudding, jam, jelly, seasonings, fruit filling, sweetener, yeast paste, salad seasonings, cakes, meat pulp, minced meat, veil fat and edible oil
3. Candy: Syrup, thin cream filling and chocolate
4. Cosmetic: Face cream, lotion, hair dye and essential oil
5. Medicine: Pill paste, extract, emulsifying agent and ointment
6. Chemical: Fat, solvent, resin, polymer and dyestuff
Infinitely adjustable-speed type rotor pump
Ss304 Rotary Lobe Pump for Chocolate, Honey, Ice Cream, Cosmetic
Wenzhou longwan wanyuan food machinery factory
The below is our pump specification:
| Model | Discharged Capacity liter per 100 revolution | RPM | Discharged Capacity (m3/h) | Power (kw) | Pump Discharged Pressure(bar) | |
| |
| ZB3A-3 | 3 | 200-500 | 0.3-0.8 | 0.75 | The maximum pressure is 3 bar when water is test standard. The greater viscosity, the larger pressure. The maximum can reach 8 bars. | |
| ZB3A-6 | 6 | 200-500 | 0.65-1.6 | 1.5 | |
| ZB3A -8 | 8 | 200-500 | 0.85-21.6 | 1.5 | |
| ZB3A -12 | 12 | 200-500 | 1.3-3.2 | 2.2 | |
| ZB3A -20 | 20 | 200-400 | 2.1-5.4 | 3 | |
| ZB3A -30 | 30 | 200-400 | 3.2-6.4 | 4 | |
| ZB3A 36 | 36 | 200-400 | 3.8-7.6 | 5.5 | |
| ZB3A -52 | 52 | 200-400 | 5.6-11 | 5.5 | |
| ZB3A -66 | 66 | 200-400 | 7.1-14 | 7.5 | |
| ZB3A -78 | 78 | 200-400 | 9-18 | 7.5 | |
| ZB3A -100 | 100 | 200-400 | 11-22 | 11 | |
| ZB3A -135 | 135 | 200-400 | 15-30 | 15 | |
| ZB3A -160 | 160 | 200-400 | 17-34 | 18.5 | |
| ZB3A A-200 | 200 | 200-400 | 21.6-43 | 22 |
