Rotor pump used in thick liquid
This type pump's driving system adopts step-less variator +motor. The speed regulator changes the speed by manual adjustment, which is safe, reliable and infinitive flow adjustment. But the non-automatic adjustment is also troublesome. Speed regulating should be done in operation not in shutoff state.
The pump is widely used to deliver: Various special material, stiff material, mixture with different specific gravity, corrosive material and material with large power.
The pump is applied in food, daily chemicals, pharmacy, chemical industry.
Advantage:
1. Stable work
2. Low noise
3. Easy assembly and disassembly
4. Conveniently clean
Usage:
1. Dairy product: Sour and fresh milk, ice cream, cream slices and whey
Beverage: Beer, mash, yeast, aerated water, concentrated fruit solution and fruit juice drinks
2. Food: Ketchup, fruit paste, vegetable pulp, pudding, jam, jelly, seasonings, fruit filling, sweetener, yeast paste, salad seasonings, cakes, meat pulp, minced meat, veil fat and edible oil
3. Candy: Syrup, thin cream filling and chocolate
4. Cosmetic: Face cream, lotion, hair dye and essential oil
5. Medicine: Pill paste, extract, emulsifying agent and ointment
6. Chemical: Fat, solvent, resin, polymer and dyestuff
Infinitely adjustable-speed type rotor pump
Main application characteristics:
1)High viscosity material feeding pump
2)Thin medium feeding pump
3)Sanitary feeding pump
4)Heat preservation sleeve design
5)Water cleaning mechanical seal
6)Almost have no consumable parts
Ss304 Rotary Lobe Pump for Chocolate, Honey, Ice Cream, Cosmetic
Wenzhou longwan wanyuan food machinery factory
The below is our pump specification:
| Model | Discharged Capacity liter per 100 revolution | RPM | Discharged Capacity (m3/h) | Power (kw) | Pump Discharged Pressure(bar) | |
| |
| ZB3A-3 | 3 | 200-500 | 0.3-0.8 | 0.75 | The maximum pressure is 3 bar when water is test standard. The greater viscosity, the larger pressure. The maximum can reach 8 bars. | |
| ZB3A-6 | 6 | 200-500 | 0.65-1.6 | 1.5 | |
| ZB3A -8 | 8 | 200-500 | 0.85-21.6 | 1.5 | |
| ZB3A -12 | 12 | 200-500 | 1.3-3.2 | 2.2 | |
| ZB3A -20 | 20 | 200-400 | 2.1-5.4 | 3 | |
| ZB3A -30 | 30 | 200-400 | 3.2-6.4 | 4 | |
| ZB3A 36 | 36 | 200-400 | 3.8-7.6 | 5.5 | |
| ZB3A -52 | 52 | 200-400 | 5.6-11 | 5.5 | |
| ZB3A -66 | 66 | 200-400 | 7.1-14 | 7.5 | |
| ZB3A -78 | 78 | 200-400 | 9-18 | 7.5 | |
| ZB3A -100 | 100 | 200-400 | 11-22 | 11 | |
| ZB3A -135 | 135 | 200-400 | 15-30 | 15 | |
| ZB3A -160 | 160 | 200-400 | 17-34 | 18.5 | |
| ZB3A A-200 | 200 | 200-400 | 21.6-43 | 22 |
