| Customization: | Available |
|---|---|
| Automatic Grade: | Manual |
| Application: | Milk, Liquid |
| Quantity: | |
|---|---|
sanitary beverage pump features:
1. It is suitable for transporting high viscosity, ensity and any medium containing particle.
2. The rotational speed is low, generally keep already existing quality not changing , any physics and chemistry properties won't be changed.
3. LQ3A Stainless Steel stainless steel food grade Pump can be also called colloidal pump. All liquid flowing parts are made of stainless steel. It can transmit high viscosity, thickness and with particle medium.
4. High pressure of out let makes sure the long distance and high resisitance transportation with stable capacity used widely in health ,food ,chemical, industial areas .
5. Suitable temperature: -30 °C to 200 °C
Wenzhou wanyuan food machinery factory——sanitary beverage pump
| Model | Discharge Capacity per 100r (L) | Speed range (rpm) | Flow (L/H) | Motor power (kW) |
| LQ3A-6 | 6 | 200~500 | 650~1600 | 1.5 |
| LQ3A-8 | 8 | 200~500 | 850~2160 | 1.5 |
| LQ3A-12 | 12 | 200~500 | 1300~3200 | 2.2 |
| LQ3A-20 | 20 | 200~500 | 2100~5400 | 3 |
| LQ3A-30 | 30 | 200~400 | 3200~6400 | 4 |
| LQ3A-36 | 36 | 200~400 | 3800~7600 | 5.5 |
| LQ3A-52 | 52 | 200~400 | 5600~11000 | 5.5 |
| LQ3A-66 | 66 | 200~400 | 7100~14000 | 7.5 |
| LQ3A-78 | 78 | 200~400 | 9000~18000 | 7.5 |
| LQ3A-100 | 100 | 200~400 | 11000~22000 | 11 |
| LQ3A-135 | 135 | 200~400 | 15000~30000 | 11 |
