Liquid Shampoo Filling and Packaging Machine

Customization:	Available
Type:	Rotary Filling Machine
Automatic Grade:	Automatic

Quantity:



Inquire Add to Basket

Product Description

Basic Info.

Filling Valve Head

Single-Head

Feed Cylinder Structure

Single-Room Feeding

Dosing Device

Capacity Cup

Filling Principle

Negative Pressure

Packaging Container Lifting Structure

Chute Lifting

Structure

Linear

Packaging

Bag

Packaging Material

Plastic

Capacity

20-60 Bags/ Min

Packing Capacity

5-100 Ml

Power

1.4kw 220V 50Hz

Bag Size

150*120mm

Overall Dimensions

800*1000*1800mm

Weight

300kg

Transport Package

Wooden Case

Origin

Wenzhou China

Product Description

Liquid shampoo automatic Filling and packaging Machine

Packing process:
Release film pull bags---Heat sealing---Filling---Bag cutting unit---Packaging products

The whole machine by: piston volume metering device, the film transport device, vertical heat sealing device, cross-cutting heat sealing equipment, electricnic control part of the rack unit and other components. All parts in contact with the material are stainless steel 304.
Liquid Shampoo Filling and Packaging Machine

Technical parameters

Model	S100	S300	S500
Production capacity(60bags/min)	30-60	25-50	20-40
pack size (ML)	5-100	50-300	100-500
Power	1.4Kw/ 220V/50hz	1.4Kw/ 220V/50hz	1.4Kw/ 220V/50hz
Bag Size (Length)	150mm	300mm	300mm
Bag Size (Width)	120mm	120mm	190mm
Dimensions (mm)	80010001800	80015002000	100018002200
weight (kg)	300	480	500
