Hot water spray sterilizer Counter pressure autoclave sterilizer vacuum package sterilizer steam sterilizer retort autoclave vacuum package sterilizer
Is ideal to be a secondary sterilization equipment for foods packed in bags or boxes or glass bottles as well as tin cans.
1. Hot water spraying sterilization kettle is ideal to be a secondary sterilization equipment for foods packed in bags or boxes. And it is an automatic system composed of technical tanks, heat exchangers, water flow distributors, various pumps, and valves, connecting pipes, PLC and touch screen
2. Hot water spray rotort sterilizer peforms various types of high-pressure sterilization. Sterilization is achieved through the use of non-atomized hot water droplets. The sterilized comprises a retort that is capable of receiving multiple trays of materials, a pressurized air intake system for introducing pressurized air in to the retort, an exhaust system and multiple spray unit capable of spraying liquid such that at least one spray unit is disposed adjacent to each tray of material
3. It is widely applied for meat, aquatic products, vegetables, soups, and juices, box rice, leisurely foods etc.
Steam sterilizer autoclave picture: Sterilizer retort machine for food | Model | GT7C 720 | GT7C 1200 | GT7C 2000 | GT7C 2400 |
| Category | Elementary Pressure Vessel |
| Internal Diameter (mm) | 900 | 1000 | 1100 | 1200 |
| Volume( m³) | 1.2 | 2 | 3.5 | 4.2 |
| Design Temperature | 143 degree C |
| Working Temperature | 123 degree C |
| Design Pressure | 0.3 MPa |
| Working Pressure | 0.15 MPa |
| Working Medium | water\steam\compressed air |
| Main Pressure Part Material | SS304 |
| Welding Coefficient | 0.7 |
| Corrosion Allowance | 1mm |
| Net Weight(kg) | 600 | 1100 | 1700 | 2000 |
| External Dimensions(mm) | length | 2100 | 2800 | 3700 | 4000 |
| Width | 1300 | 1450 | 1600 | 1600 |
| height | 1650 | 1700 | 1800 | 1900 |
