Autoclave description
An autoclave is a pressure chamber used to sterilize product and supplies by subjecting them to high pressure saturated steam at 121°C (249°F) for around 15-20 minutes depending on the size of the load and the contents.
Sterilization autoclaves are widely used in microbiology, medicine, podiatry, tattooing, body piercing, veterinary science, mycology, dentistry, and prosthetics fabrication. They vary in size and function depending on the media to be sterilized.
| Model | GT7C 720 | GT7C 1200 | GT7C 2000 | GT7C 2400 | |
| Category | Elementary Pressure Vessel | ||||
| Internal Diameter (mm) | 900 | 1000 | 1100 | 1200 | |
| Volume( m³) | 1.2 | 2 | 3.5 | 4.2 | |
| Design Temperature | 143 degree C | ||||
| Working Temperature | 123 degree C | ||||
| Design Pressure | 0.3 MPa | ||||
| Working Pressure | 0.15 MPa | ||||
| Working Medium | water\steam\compressed air | ||||
| Main Pressure Part Material | SS304 | ||||
| Welding Coefficient | 0.7 | ||||
| Corrosion Allowance | 1mm | ||||
| Net Weight(kg) | 600 | 1100 | 1700 | 2000 | |
| External Dimensions(mm) | length | 2100 | 2800 | 3700 | 4000 |
| Width | 1300 | 1450 | 1600 | 1600 | |
| height | 1650 | 1700 | 1800 | 1900 | |
Autoclave description
An autoclave is a pressure chamber used to sterilize product and supplies by subjecting them to high pressure saturated steam at 121°C (249°F) for around 15-20 minutes depending on the size of the load and the contents.
Sterilization autoclaves are widely used in microbiology, medicine, podiatry, tattooing, body piercing, veterinary science, mycology, dentistry, and prosthetics fabrication. They vary in size and function depending on the media to be sterilized.
| Model | GT7C 720 | GT7C 1200 | GT7C 2000 | GT7C 2400 | |
| Category | Elementary Pressure Vessel | ||||
| Internal Diameter (mm) | 900 | 1000 | 1100 | 1200 | |
| Volume( m³) | 1.2 | 2 | 3.5 | 4.2 | |
| Design Temperature | 143 degree C | ||||
| Working Temperature | 123 degree C | ||||
| Design Pressure | 0.3 MPa | ||||
| Working Pressure | 0.15 MPa | ||||
| Working Medium | water\steam\compressed air | ||||
| Main Pressure Part Material | SS304 | ||||
| Welding Coefficient | 0.7 | ||||
| Corrosion Allowance | 1mm | ||||
| Net Weight(kg) | 600 | 1100 | 1700 | 2000 | |
| External Dimensions(mm) | length | 2100 | 2800 | 3700 | 4000 |
| Width | 1300 | 1450 | 1600 | 1600 | |
| height | 1650 | 1700 | 1800 | 1900 | |
