Small model electric heating sterilizer retort
Wanyuan Brand Electric heating autoclave(sterilizer)
1. Counter pressure Sterilizer
2. Food sterilizer(steam sterilizer, retort sterilizer)
Sterilization machine Classification
1. According to heating type: Steam Heating UHT and Electric Heating sterilizer
2. According to material: SUS304 and SUS316L
High pressure Sterilizer
Retort sterilizer(high pressure sterilizer ) adopts casing structure, has the characteristics such as high efficiency, energy saving and simple operation. Due to the short heating time, small nutrition loss.
Sterilizer is suitable for the liquid material beverage. Such as fresh milk, fruit juice drink, wine drink, soybean milk and Chinese medicine, as well as the sticky material (for example, sweet condensed milk) upon completing with high-pressure homogenizer.
If the homogenizer is set together, autoclave sterilizer can also be used for high viscosity materials such as sugar beets and condensed milk and so on.
Please used for health &sanitation.
Vertical autoclave(electric heating sterilizer)
Autoclave, it's used for beverage &food industry.
1. It is small scale electric autoclave.
2. Small land area, suited in Lab.
3. The working temperature range: 100-135C.
4. The Max temperature: 143C.
5. With control box, temperature meter, pressure meter, safe valve etc.
6. Made of stainless steel 304, outer and inner polishing to easy cleaning.
7. Electric power
Wenzhou Wanyuan Food Mechanical Fatory
Small model electric heating sterilizer retort
Here below the autocalve sterilizer retort specification:
| Model | GT7C1.1 |
| Inner Dia | DN1100 |
| Trolley | 2 |
| Capacity | 1.5 m3 |
| Max Working Pressure | 0.3 Mpa |
| Max Working Temperature | 143 degree |
| Equipment Weight | 650kgs |
| Equipment Dimensio | 22000×1300×2160mm |
