Dairy Making Machine Milk Cooling Tank
Cooling pot is usually as vertical cooling milk pot's abbreviation, so the cooling pot is mainly used for cooling, storage (store) milk or other liquid materials. Is the main form a complete set of farm mechanization milking equipment, more suitable for the manual milking farms and milk collection station, cooling collection store dairy milk. Best cooling milk protection, prevent bacterial breeding.
Usage of milk cooling tank
Cooling pot is widely used in the dairy, beverage, pharmaceutical and other industries in milk or other liquid cooling and storage.
Features of Milk Cooling Tank
1. Cooling fresh cow milk to exent the storage time
2. Temperature controlled automaticaly
3. Cooling fresh milk to 0~4 degree in short time
4. USD world famous compressor brand such as copeland.
Structures of Vertical Milk Cooling Tank
Vertical cooling milk pot is mainly composed of pot body, stirrer, washing machine, cooling unit and electric control boxes.
Milk pot is a horizontal elliptic form, between the inside and outside pot is poly amino ester hard foam board, the material has low thermal conductivity, light proportion, high strength, and low bibulous rate.
Wenzhou wanyuan food machinery factory- - Milk cooling tank
Here below the milk cooling tank specification
| Milk cooling tanks specification |
| Model | Capacity(L) | Cooling capacity(W) | Stirring speed ( R/MIN) | Match power(KW) | dimension(L*M*H) |
| MCT-0.5 | 500 | 3500 | 36(24)R/MIN | 1.5 | 2200*1350*1150 |
| MCT-1 | 1000 | 6900 | 36(24)R/MIN | 3 | 2750*1150*1500 |
| MCT-1.5 | 1500 | 10000 | 36(24) R/MIN | 4 | 3000*1350*1550 |
| MCT-2 | 2000 | 13000 | 36(24)R/MIN | 5 | 3200*1500*1600 |
| MCT-3 | 3000 | 17800 | 36(24)R/MIN | 6.5 | 3500*1650*1700 |
| MCT-5 | 5000 | 34000 | 36(24)R/MIN | 13 | 4000*1950*2000 |
| MCT-6 | 6000 | 34000 | 36(24)R/MIN | 13 | 4200*2200*2100 |
| MCT-8 | 8000 | 42000 | 36(24)R/MIN | 18 | 4800*2400*2400 |
| MCT-10 | 10000 | 65000 | 36(24)R/MIN | 24 | 5000*2600*2500 |
